Description
Key Features
- Lithium Complex Grease.
- Totally Enclosed Fan Cooled Enclosure.
- Position Of Terminal Box at Top Drive End.
Product Specifications
|
Brand
|
|
|
AC or DC
|
AC
|
|
Motor Power
|
7.5 HP
|
|
Mounting type
|
Foot Mounted
|
|
Power Rating
|
5.5 kW
|
|
Ambient Temperature
|
50°C
|
|
Body Material
|
Cast Iron
|
|
Cage type
|
Squirrel Cage
|
|
Class of insulation
|
F Class
|
|
Efficiency
|
IE2
|
|
Frame Size
|
132 mm
|
|
Frequency
|
50 Hz (±5%)
|
|
Item Code
|
3GBA132110-ADCIN
|
|
Model
|
M2BAX132SA4 IE2
|
|
Motor Winding
|
Copper
|
|
Number of Poles
|
4
|
|
Protection Class
|
IP55
|
|
Speed
|
1500 rpm
|
|
Voltage
|
415 V
|
|
Phase
|
Three Phase
|
|
Standards
|
CE, IEC60034-1, Ref:IS12615:2011
|
|
Warranty
|
12 Months from Dispatch
|
|
Weight
|
90 kg
|
|
Country of origin
|
India
|
